TYLER TEST SIEVE SHAKER

sieve shaker

Technical Data:

Operating voltage: 230 Volt, 50 Hertz or 110 Volt, 60 Hertz

Time Switch: 0-99 minutes – digital

Revolutions/min: 150

Tappings/min: 150

Sound emission: 86 dB^A

Weight approx. 112kg

Dimensions: 710x540x640mm (w x d x h)

Feed quantity: max. 3kg

RX29:

6 standard or 13 half height test sieves 08”/0203mm or 0200mm and one sieve pan

RX30:

5 standard or 8 half height test sieves 012”/0305mm or 0300mm and one sieve pan

Article.No.

Article.No.

RX29-10 230 Volt, 50 Hertz- ( not conform to CE- Standard)

650 351

650 320

RZ29    110Volt,60 Hertz- (not conform to CE-Standard)

650 352

650 321

RX30-10  230Volt, 50 Hertz- (not conform to CE-Standard)

650 353

650 322

Sound Enclosure (from 85dB to 78Db) All controls inside/Shipping: 89cm x 61cm x 74cm,Weight 76kg

650 355

650 354

(*) ex works USA (**) ex works Germany/ Haver & Boecker who owns Tyler is bind to certain trade agreements. Tyler can only deliver the non conform CE Standard to Haver & Boecker



tyler- test

Technical Data:

Operating voltage: 230 Volt, 50 Hertz or 110 Volt, 60 Hertz

Time Switch: 0-99 minutes – digital

Revolutions/min: 150

Sound emission:_>70dB^A

Weight approx. 154 kg

Dimensions: 710 x 530 x 635mm (w x d x h)

Feed quantity: max 3kg

RX29:

6 standard or 13 half height test services 08”/0203mm or 0200mm and one sieve pan

RX30:

5 standard or 8 half height test sieves 012”/0305mm or 0300mm0 and one sieve pan

Article-no.

RX29 230volt, 50 Hertz- conform to CE-Standard

650 420

RX30 230Volt,50Hertz- conform to CE- Standard

650 421

tyler-test
